Veritas R8 Plus & Excel Installation Manual Quick Reference and Factory Settings
INS045-14 5
Programming Option Option Code Programming Procedure Factory Setting
Zone Disable Suite
Select Zone Number(s)
to
Press
No Zones Included
Zone Soak Test Suite
Select Zone Number(s)
to
Press
No Zones Included
Full Set Suite
Select Zone Number(s)
to
Press
All Zones Included
Part Set Suite 1
Select Zone Number(s)
to
Press
Zones 5, 6, 7 Omitted
Part Set Suite 2
Select Zone Number(s)
to
Press
Zones 5, 6, 7 Omitted
Part Set Suite 3
Select Zone Number(s)
to
Press
Zones 5, 6, 7 Omitted
Part Set Suite 4
Select Zone Number(s)
to
Press
Zones 5, 6, 7 Omitted
Chime Suite
Select Zone Number(s)
to
Press
No Zones Included
Cleaner Suite
Select Zone Number(s)
to
Press
No Zones Included
Double Knock Suite
Select Zone Number(s)
to
Press
No Zones Included
Manual Omit Suite
Select Zone Number(s)
to
Press
Zone 1 Omitted
Zone Invert Suite
Select Zone Number(s)
to
Press
No Zones Included
Program Your Own Code PIN
Enter New Code PIN
Press
Program Code 1 PIN
Enter New Code PIN
Press
Program Code 2 PIN
Enter New Code PIN
Press
Program Code 3 PIN
Enter New Code PIN
Press
Program Code 4 PIN
Enter New Code PIN
Press
Program Code 5 PIN
Enter New Code PIN
Press
Program Code 6 PIN
Enter New Code PIN
Press
Program Code 7 PIN
Enter New Code PIN
Press
Program Code 8 PIN
Enter New Code PIN
Press
Display Your Own User Number
View Display Press
Display Panel Type
View Display Press
Z1, Z2, Z3 On
Program Code 1 Access Level
Select Access Level
to
Press
Master User (5)
Program Code 2 Access Level
Select Access Level
to
Press
Boss Engineer (8)
Program Code 3 Access Level
Select Access Level
to
Press
Null (7)
Program Code 4 Access Level
Select Access Level
to
Press
Null (7)
Program Code 5 Access Level
Select Access Level
to
Press
Null (7)
Program Code 6 Access Level
Select Access Level
to
Press
Null (7)
Program Code 7 Access Level
Select Access Level
to
Press
Null (7)
Program Code 8 Access Level
Select Access Level
to
Press
Null (7)
Display Your Own Access Level
View Display Press
Communicator Interface Selections
Select/De-select Option Number(s)
to
Press
Test Communicator Interface
Toggle Channel(s)
to
Press
Reference Table
Number Test Outputs
SW= Function
Zone Types
Extended Display
0 All Off
1 Bell Set +Ve Push To Set Bell & Global Tamper
2 Strobe Alarm +Ve & Reset Inhibit Entry Power
3 Sounder Lo Reset Guard Lid Tamper (inc. RKP)
4 Sounder Hi Tamper Fire Line Monitor
5 SW+ Mains Fail Tamper RKP Off-Line
6 Engineer Hold Off Set +Ve & Reset Entry/Exit Code PIN Tamper
7 Walk Test PA Keypad PA
8 Entry/Exit Keyswitch EOL Tamper
To Next Page
