EN
CAUTION: Turn o the power before start this operation.
Raise the needle by turning the balance wheel toward you.
1. Open the hook cover.
2. Take out bobbin case holding the latch.
3. When inserting the bobbin case, place the tip of the bobbin case into the recess of the hookrace.
1. Place bobbin into bobbin holder with the thread unwinding counter clockwise.
2. Draw thread into notch.
3. Pull thread toward the left and along the inside of spring until it slips into notch being sure that
thread does not slip out of notch. Pull thread out about 10 cm.
REMOVING OR INSERTING THE BOBBIN CASE
INSERTING THE BOBBIN
gap
Texi Joy 48 67
