ZT 220D

Series

ITEM PART NO. DESCRIPTION QTY

9-1 2720866 HARNESS-WIRING 1

(INCLUDES ITEMS 2, 19, 20 & 21)

9-2 148082-20 FUSE-20 AMP 1

9-3 2218089 CABLE-BATTERY 1

9-4 158135-01 SWITCH-SEAT NO 1

9-5 158136 WIRE-SEAT SWITCH 1

9-6 48030N HOUR METER ASSY 1

9-7 2198092 CABLE-GROUND 1

9-8 2721126 KEY-SWITCH W/BEZEL 1

9-9 128037 RELAY 8

9-10 2188154 MODULE-DELAY 1

9-11 2188153 SWITCH-CLUTCH 1

9-12 2721337 CLUTCH 1

(INCLUDES ITEM 27)

9-13 2188172 HARNESS-JUMPER 2

9-14 108208 SWITCH-DBL POLE 3

9-15 2720886 TEMP-GAUGE 1

9-16 2720887 TEMP-SENDER 1

9-17 2198089 LAMP HOLDER 1

(INCLUDES QTY 2 OF ITEM 18)

9-18 178092-22 LAMP 2

9-19 148082-10 FUSE-10 AMP 1

9-20 148082-30 FUSE-30 AMP 1

9-21 1003416 DIODE 4

9-22 188015 LENS-OIL PRESSURE 1

9-23 2198088 LENS-BATTERY 1

9-24 FUEL PUMP 1

(AVAILABLE THROUGH YANMAR DEALER)

9-25 48524 CIRCUIT BREAKER 1

9-26 2721059 CABLE-CIRCUIT BREAKER 1

9-27 2720949 WIRE-ASSEMBLY CLUTCH 1

9-28 38382 SWITCH-NO 1

2721543-09

FIGURE 9

YANMAR WIRE HARNESS

Textron BOB-CAT ZT 220D Series User Manual
