PART NO. DESCRIPTION FIG/ITEM PART NO. DESCRIPTION FIG/ITEM
CROSS REFERENCE
ZT 220D
Series
64
1003416 SWITCH-IGNITION 9 /21
108029 PLUG,MAGNETIC 7 /4
108094-01 CLAMP-HOSE SAE20 11 /8
108194-06 CHANNEL,FLEX TRIM SEAL 11 /2
108194-06 CHANNEL,FLEX TRIM SEAL 11 /3
108194-13 FLEX TRIM 41.00 11 /26
108194-13 FLEX TRIM 41.00 11 /27
108205-03 ELBW, MALE 45 8X10 37-ORB 7 /6
108208 SWITCH DBL POLE 1 /35
108208 SWITCH DBL POLE 9 /14
112111-02 BLADE 18.00 OFFST HLFT 16 /12
112111-03 BLADE 21.00 OFFST HLFT 16 /12
118020-15 CABLE-THROTTLE 44.5 10 /14
128003 BELT-CUTTER DECK 17 /3
128011 PULLEY, DECK DRIVE 16 /20
128037 RELAY 9 /9
128102 SPRING,EXTENSION 6 /4
128169 PULLEY, IDLER 5.50 16 /24
142088.7 BRACKET-ROLLER 16 /13
146067 WLDMT-ROLLER SHAFT 16 /11
148034-06 INSUL.GROMMET 0.5 I.D. 12 /32
148034-08 GROMMET 1.125OD .625ID 12 /31
148034-09 GROMM 7/8 X 3/8 X 3/8 12 /28
148034-10 GROMMET-2 X 1-1/2 X 3/8 11 /9
148042 BALL BRG 1.00 10 15 /7
148074 BATTERY-BCI 26 1 /4
148082-10 FUSE 10 AMP 9 /19
148082-20 FUSE 20 AMP 9 /2
148082-30 FUSE 30 AMP 9 /20
148263-10 S HSE .56 X .31 X 35.0 10 /34
148263-10 S HSE .56 X .31 X 35.0 10 /35
158058-04 FITTING-BARB 90, ADJ 7 /5
158058-07 FITTING-90 BARB, ADJ 7 /11
158122-02 TUBING-SIGHT GLASS 10 /28
158135-01 SWITCH-SEAT, NO 13 /4
158135-01 SWITCH-SEAT, NO 9 /4
158136 WIRE-SEAT SWITCH 13 /9
158136 WIRE-SEAT SWITCH 9 /5
178092-22 LIGHT FOR ROCKER 9 /18
188015 OIL PRESSURE LENS 9 /22
188059-11 S SWASH PLATE #2003087 8 /32
188059-13 S BRG CRADLE #2003023 8 /47
188059-15 S ARM-TRUNION #2003005 8 /37
188059-16 S BEARING AND HOUSING KIT 8 /39
188059-9 S GUIDE SLOT #2000015 8 /38
1985039 AIR CLEANER 11 /18
2000572 LABEL-WARNING BLADES 18 /1
2000577 LABEL, WARNING 18 /2
2000590 LABEL, WARN BATTERY 4 /4
2000677 LABEL-DANGER/WARNING 18 /4
2000691 LBL - HYDR OIL FILL 4 /5
2000693 LBL - PARK BRAKE 4 /7
2000695 LBL - WARN/USING 3 /27
2000695 LBL - WARN/USING 4 /14
2000696 LBL - BLADE INSTALL 18 /3
2000698 LBL(DBL) - FUEL/LEAKS 4 /8
2000700 LBL - RH TRACTION 4 /10
2000701 LBL - LH TRACTION 4 /11
2000705 LABEL-TIRES 4 /9
2000706 LABEL-FUEL 4 /15
2000735 LABEL-OPER MAN 4 /3
2000785 LABEL-RED/WHITE STRIPE 3 /28
2000785 LABEL-RED/WHITE STRIPE 4 /1
2182344.7 LEVER-CONTROL 14 /5
2182351.2 BELT COVER LH 16 /66
2182352.2 BELT COVER RH 16 /65
2182356.7 BRKT-SHAFT HANGER 3 /3
2182368.7 BRKT-LIFT LINK 14 /26
2182387.7 GUIDE-SPRING 6 /7
2182391.7 PLATE-SEAT 13 /10
2182404.7 PLATE-KICK 1/41
2182405.7 BRKT-REVERSE RETURN 1/18
2182427.7 HOLDDOWN-BATTERY 1/32
2182434.7 BRKT-TRACTION LEVER 14 /6
2182437.7 GUIDE-BELT 16 /54
2182442.7 BRACE-VERTICAL 5 /6
2182458.2 BELT COVER RH 16 /2
2182459.2 BELT-COVER LH 16 /3
2182474.7 GUIDE-BELT 16 /49
2182493.7 BAFFLE-FRONT LH 16 /48
2182494.7 BAFFLE-FRONT RH 16 /42
2182495.7 BAFFLE-FRONT LH 16 /59
2182496.7 BAFFLE-FRONT RH 16 /60
2183052 ROD-LIFT 3 /11
2183056 SHAFT, BRAKE 6 /11
2183063-01 SPACER, 32MM LONG 6 /19
2183064 ROD-BRAKE 6 /30
2183069 ROD-PROP 13 /12
2183070-01 SHAFT-SPINDLE 16 /37
2183070-02 SHAFT-SPINDLE 16 /37
2183071-03 SPACER 14 /36
2183073 SPACER 14 /19
2186120.7 WLDMT-DECK HANGER 3 /4
2186125 WLDMT-LOCK, PUSHBAR 16 /32
2186128.7 WLDMT-BRAKE ARM LH 6 /2
2186130.7 WLDMT-LIFT SHAFT REAR 3 /10
2186132 S 61 CUTTERDECK W/LABS 16 /64
2186138.7 WLDMT-DECK IDLER 16 /25
2186140.7 WLDMT-PTO IDLER 16 /15
2186142.7 WLDMT-BRAKE ARM RH 6 /3
2186143.7 WLDMT-BRAKE LEVER ARM 6 /5
2186164.7 WLDMT-DECK IDLER 16 /25
2186167.7 WLDMT-CONTROL SHFT LH 1/29
2186167.7 WLDMT-CONTROL SHFT LH 14 /12
2186168.7 WLDMT-CONTROL SHFT RH 14 /12
2186171.7 WLDMT-PUMP ARM 1 /13
2186179 S-52 DECK W/LABS 16 /1
2186185.7 WLDMT-PUSHBAR 16 /28
