©Copyright Task Force Tips, Inc. 2004-2018 LIX-530 December 31, 2018 Rev14
23
EXTEND-A-GUN RC3 & rc4
ITEM PART DESCRIPTION PART # QTY
1 3/4"NPTM HEX SOCKET PLUG XG410 1
2
INLET 3.0"NPT MALE XG405PL
1
INLET 3.0"BSP MALE (NOT SHOWN) XG405BL
INLET 3.0"VICTAULIC MALE (NOT SHOWN) XG405VL
MALE INLET 4.0"NPT (NOT SHOWN) XGE505PP
MALE INLET 4.0"BSPM (NOT SHOWN) XGE505BP
MALE INLET 4.0" VICTAULIC (NOT SHOWN) XGE505VP
3
O-RING-VO-343 3-3/4 ID 3/16 C/S (RC3) VO-343
1
O-RING-VO-351 4-3/4 ID X 3/16 C/S (RC4) VO-351
4
3" OUTER TUBE 12" TRAVEL XGE608
13" OUTER TUBE 18" TRAVEL XGE606
4" OUTER TUBE 18" TRAVEL XGE601
5 TRUNNION-STATIONARY XGE610 2
6 WASHER 304 STAINLESS (RC3 ONLY) VW1.3X88-125 2
7
CUP SEAL 3/16 X 3.375 X 3.750 (RC3) XG125
1
CUP SEAL 4.25 X 4.75 X 1/4 (RC4) XGE380
8
3" INNER TUBE 12" TRAVEL XGE607
13" INNER TUBE 18" TRAVEL XGE605
4" INNER TUBE 18" TRAVEL XGE600
9 MAGNET VM4170 1
10
CUP SEAL 3.50"ID X 4.00"OD X 1/4" (RC3) XGE613
1
CUP SEAL 4.50"ID X 5.00"OD X 1/4" (RC4) XGE614
11 1/4-20 X 3/4 SOCKET HEAD SCREW VT25-20SH750 4
12 GEAR MOTOR; EXTEND-A-GUN - SUBASSEMBLY XGA950 1
20
1/4-20 X 2 3/4 SOCKET HEAD SCREW (RC3) VT25-20SH2.7
2
1/4-20 X 2 1/2 SOCKET HEAD SCREW (RC4) VT25-20SH2.5
21 MOUNTING BLOCK XGE620 1
22 REED SWITCH XGE695-KIT 1
23 LATCH SPRING XGE625 1
24 DOWN LATCH XGE621 1
25 BUSHING NYLON X252 2
26 SHAFT WITH GEAR XGE622 1
27 1/4-20 HEX NUT VT25-20NT 1
30 1/4-20 X 1/2 SOCKET HEAD SCREW VT25-20SH500 3
31 3/8 LOOP CLAMP XGE638 1
32 REDUCER HOUSING XGE630 1
33 RELEASE LEVER XGE623 1
34 PIVOT PIN XX535 1
35 HANDLE TORSION SPRING A4263 1
36 UP LATCH XGE633 1
40 SPROCKET 38 TEETH XGE632 1
41 THIN WASHER A1530 1
42 BUSHING XGE637 1
43 DRIVING SPROCKET 12 TEETH XGE635 1
44 SHORT HEADED BUSHING XGE634 1
45 58 LINK ROLLER CHAIN XGE636 1
46 REDUCER COVER XGE631 1
47 1/4-20 X 1-1/4 SOCKET HEAD SCREW VT25-20SH1.25 2
48
NAME LABEL: RC3 EXTEND-A-GUN XGEL630
1
NAME LABEL: RC4 EXTEND-A-GUN XGEL640
49 1/4-20 X 1/2 BUTTON HEAD SCREW VT25-20BH500 2
50 KNOB Z245 1
