3.3 DIMENSIONS

18” EXTEND-A-GUN RC4

4” Waterway 18” travel

8.5"

ALTERNATE:

1) MOUNTING PLATE 11" SQUARE

TFT P/N XGB-43

4" NPT MALE

4" BSP MALE 4" VICTAULIC MALE FROM PUMP

Ø6"

SEE LOAD CHART

FOR DISTANCE

SADDLE BRACKET

TFT P/N XGB-53

SADDLE BRACKET

OUTER TUBE

(POSITION ADJUSTABLE

BY U-BOLTS IN MOUTING TUBE)

23 3/4" 21.7" RETRACTED

SHOWN WITH

TFT MASTER 2000 ERP NOZZLE

AND

MONSOON RC MONITOR

23.6"

EXTENDED

TRUCK SURFACE

Fig 3.3c
