TFT ULTIMATIC User Manual

©Copyright Task Force Tips LLC 2002-2021 11 LIN-030 May 21, 2021 Rev18
Figure 4.4G
Figure 4.4H
Handline 75 psi (5 bar) Version
Curve
A B C D A B C D
Flow (gpm)
95 125 200 250 (L/min) 360 473 757 946
Pressure (psi)
68 72 78 81 (bar) 4.7 5.0 5.4 5.6
Reaction (lbs)
40 54 89 113 (kgf) 18 25 40 51
Handline 55 psi (3 bar) Version
Curve
A B C D A B C D
Flow (gpm)
95 125 175 225 (L/min) 360 473 662 852
Pressure (psi)
48 52 60 71 (bar) 3.3 3.6 4.1 4.9
Reaction (lbs)
33 46 68 96 (kgf) 15 21 31 44
MODEL
H-VPGI
SHOWN
HANDLINE 75 PSI (5 BAR) VERSION
Automatic Pressure Control Flow Range:
95-250 gpm @ 75 psi
360-950 L/min @ 5 bar
75 psi/ 5 bar Version
55 psi/ 3 bar Version
HANDLINE 55 PSI (3 BAR) VERSION
Automatic Pressure Control Flow Range:
95-225 gpm @ 55 psi
360-850 L/min @ 3 bar
