2. Specications
Model
GWART24S2
GRART24AS2
GWHART24S2
GRHART24AS2
Product Code CB464006500_116777 CB464006600_116777
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 22000 22000
Heating Capacity Btu/h / 24000
Cooling Power Input W 1800 1800
Heating Power Input W / 1927
Cooling Power Current A 9.00 9.0
Heating Power Current A / 8.5
Rated Input W 2600 2650
Rated Cooling Current A 12.00 12.0
Rated Heating Current A / 12.0
Air Flow Volume CFM 794/647/559/500 794/647/559/500
Dehumidifying Volume Pint/h 5.07 5.07
EER (Btu/h)/W 12.21 12.22
COP (Btu/h)/W / 12.45
SEER 21(SEER) 22(SEER2) 21(SEER) 22(SEER2)
HSPF / 10.0(HSPF) 9.0(HSPF2)
Application Area yd
2
32-50 28-41
Indoor
Unit
Model of indoor unit GWART24S2 GWHART24S2
Indoor Unit Product Code CB464N06500_116777 CB464N06600_116777
Fan Type Cross-ow Cross-ow
Fan Diameter Length(D×L) mm Ф108×830 Ф108×830
Cooling Speed r/min 1500/1150/1000/850 1500/1150/1000/850
Heating Speed r/min / 1500/1200/1050/900
Fan Motor Power Output W 60 60
Fan Motor RLA A 0.30 0.30
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7 Φ7
Evaporator Row-n Gap mm 2-1.3
2-1.3
Evaporator Coil Length (L×D×W) mm 850×25.4×381 850×25.4×381
Swing Motor Model MP35CP MP35CJ
Swing Motor Power Output W 2.5 2.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A) Cooling: 52/45/40/37
Cooling: 52/45/40/37
Heating: 52/46/42/37
Sound Power Level dB (A) Cooling: 62/55/50/47
Cooling: 62/55/50/47
Heating: 62/66/52/47
Dimension (W×H×D) inch 42 7/16×12 51/64×9 11/16 42 7/16×12 51/64×9 11/16
Dimension of Carton Box (L×W×H) inch 44 1/4×15 3/4×12 61/64 44 1/4×15 3/4×12 61/64
Dimension of Package (L×W×H) inch 44 29/64×16 1/16×13 11/32 44 29/64×16 1/16×13 11/32
Net Weight Ib 35.3 35.3
Gross Weight Ib 41.9 35.3
