Technical Information
Service Manual
2. Specications
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GRART24AS2 GRHART24AS2
Outdoor Unit Product Code CB464W06500_116777 CB464W06600_116777
Compressor Manufacturer
ZHUHAI LANDA COMPRESSOR
CO. LTD.
ZHUHAI LANDA COMPRESSOR
CO. LTD.
Compressor Model QXFS-M180zX170 QXFS-M180zX170
Compressor Oil / /
Compressor Type Rotary Rotary
Compressor LRA. A 24.00 24
Compressor RLA A 12.20 12.2
Compressor Power Input W 1350 1350
Compressor Overload Protector HPC115/95U1 KSD115ºC HPC115/95U1 KSD115ºC
Throttling Method Electron expansion valve Electron expansion valve
Set Temperature Range ºF 61~86 61~86
Cooling Operation Ambient Temperature
Range
ºF -4~122 -4~122
Heating Operation Ambient Temperature
Range
ºF / -13~75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7 Φ7
Condenser Rows-n Gap mm 2-1.4 2-1.4
Condenser Coil Length (L×D×W) mm 839×38.1×616 839×38.1×616
Fan Motor Speed rpm 800 800
Fan Motor Power Output W 60 60
Fan Motor RLA A 0.55 0.55
Fan Motor Capacitor μF / /
Outdoor Unit Air Flow Volume CFM 2070 2070
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ520 Φ520
Defrosting Method / Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure
for the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure
for the Suction Side
MPa 2.5 2.5
Sound Pressure Level dB (A) 59 59
Sound Power Level dB (A) 69 69
Dimension (W×H×D) inch 37 3/4×25 63/64×15 53/64 37 46/64×25 63/64×15 53/64
Dimension of Carton Box (L×W×H) inch
40 33/64×17 53/64×28 5/32 40 33/64×17 53/64×28 10/64
Dimension of Package (L×W×H) inch 40 5/8×17 61/64×29 1/64 40 40/64×17 61/64×29 1/64
Net Weight Ib 94.8 95.9
Gross Weight Ib 104.7 105.8
Refrigerant R410A R410A
Refrigerant Charge oz 56.4 56.4
Connection
Pipe
Connection Pipe Length ft 24.6 24.6
Connection Pipe Gas Additional Charge oz/ft 0.2 0.5
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 5/8 5/8
Max Distance Height ft 32.8 32.8
Max Distance Length ft 82.0 82.0
Note: The connection pipe applies metric diameter.
