TGM YAP1FF - Page 18

15
Technical Information
Service Manual
2. Specications
Model
GWART36S3
GRART36AS3
GWHART36S3
GRHART36AS3
Product Code CB434026100_116777 CB434026200_116777
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 33600 33600
Heating Capacity Btu/h / 34600
Cooling Power Input W 3200 3200
Heating Power Input W / 3200
Cooling Power Current A 14 14
Heating Power Current A / 14
Rated Input W 4000 4000
Rated Cooling Current A 20 20
Rated Heating Current A / 18
Air Flow Volume CFM 912/736/706/647/588/530/471 912/736/706/647/588/530/471
Dehumidifying Volume Pint/h 7.40 7.40
EER (Btu/h)/W 10.50 10.50
COP (Btu/h)/W / 10.81
SEER 20(SEER) 20(SEER2) 20(SEER) 20(SEER2)
HSPF / 9(HSPF) 8.5(HSPF2)
Application Area yd
2
55-86.11 55-86.11
Indoor
Unit
Model of indoor unit GWART36S3 GWHART36S3
Indoor Unit Product Code CB434N26100_116777 CB434N26200_116777
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Φ108×522.7×2 Φ108×522.7×2
Cooling Speed r/min 1550/1300/1200/1100/1000/950/850 1550/1300/1200/1100/1000/950/850
Heating Speed r/min / 1500/1300/1200/1100/1000/950/900
Fan Motor Power Output W 70 70
Fan Motor RLA A 0.75 0.75
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7 Φ7
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW)
mm 1074×25.4×381 1074×25.4×381
Swing Motor Model MP24BA MP24BA
Swing Motor Power Output W 1.5 1.5
Fuse Current A 5 5
Sound Pressure Level dB (A) 56/50/47/45/42/40/37
Cooling: 56/50/47/45/42/40/37
Heating: 55/50/48/45/42/40/39
Sound Power Level dB (A) 66/60/57/55/52/50/47
Cooling: 66/60/57/55/52/50/47
Heating: 65/60/58/55/52/50/49
Dimension (WXHXD) inch 53 9/64X12 53/64X9 61/64 53 9/64X12 53/64X9 61/64
Dimension of Carton Box (LXWXH) inch 56 39/64X16 29/64X13 55/64 56 39/64X16 29/64X13 55/64
Dimension of Package (LXWXH) inch 56 47/64X16 37/64X14 7/16 56 47/64X16 37/64X14 7/16
Net Weight Ib 44.1 44.1
Gross Weight Ib 54.0 54.0
