Technical Information
Service Manual
2. Specications
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GRART36AS3 GRHART36AS3
Outdoor Unit Product Code CB432W30900_116777 CB432W31000_116777
Compressor Manufacturer
ZHUHAI LANDA
COMPRESSOR CO., LTD.
ZHUHAI LANDA
COMPRESSOR CO., LTD.
Compressor Model QXFS-D280zX070 QXFS-D280zX070
Compressor Oil FW68DA or equivalent FW68DA or equivalent
Compressor Type Rotary Rotary
Compressor LRA. A 40.00 40.00
Compressor RLA A 16.00 16.00
Compressor Power Input W 2294 2294
Compressor Overload Protector / /
Throttling Method Electron expansion valve Electron expansion valve
Set Temperature Range ºF 61~86 61~86
Cooling Operation Ambient Temperature Range ºF -4~122 -4~122
Heating Operation Ambient Temperature Range ºF / -13~75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7.94 Φ7.94
Condenser Rows-n Gap mm 2-1.4 2-1.4
Condenser Coil Length (LXDXW) mm 955X38.1X704 955X38.1X704
Fan Motor Speed rpm 850 850
Fan Motor Power Output W 90 90
Fan Motor RLA A 1.50 1.50
Fan Motor Capacitor μF / /
Outdoor Unit Air Flow Volume CFM 2648 2648
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ570 Φ570
Defrosting Method / Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5 2.5
Sound Pressure Level (H/M/L) dB (A) 62/-/- 62/-/-
Sound Power Level (H/M/L) dB (A) 72/-/- 72/-/-
Dimension(WXHXD) inch 39 3/8 × 29 3/8 × 16 13/16 39 3/8 × 29 3/8 × 16 13/16
Dimension of Carton Box (LXWXH) inch
42 13/32 × 18 57/64 × 30 29/32 42 26/64 X 18 57/64 X 30 58/64
Dimension of Package(LXWXH) inch 42 33/64 × 19 1/64 × 31 57/64 42 33/64 × 19 1/64 × 31 57/64
Net Weight Ib 125.7 127.9
Gross Weight Ib 136.7 138.9
Refrigerant R410A R410A
Refrigerant Charge oz 84.7 84.7
Connection
Pipe
Connection Pipe Length ft 24.6 24.6
Connection Pipe Gas Additional Charge oz/ft 0.2 0.5
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 5/8 5/8
Max Distance Height ft 32.8 32.8
Max Distance Length ft 82.0 82.0
Note: The connection pipe applies metric diameter.
