TGM YAP1FF - 6. Function and Control; 6.1 Remote Controller Introduction

38
Technical Information
Service Manual
GRART18AS2 GRHART18AS2
13 57 9
10
6842
11
13 12
No. Name No. Name
1 Earthing wire 8 Fan terminal
2 Live wire 9 Temperature sensor
3 Communication wire 10 Overload of compressor
4 Neutral wire 11 Dred power supply
5 4-way valve 12 Dred communication
6 Electric heating of chasssis 13 E disk
7 Electronic expansion valve
5. Electrical Part
