5. Electrical Part
GRART24AS2 GRHART24AS2
No. Name No. Name
1 Earthing wire 7 Outdoor fan
2 Live wire 8 Temperature sensor
3 Neutral wire 9 Overload
4 Communication cable 10 Three-phase terminal of compressor
5 4-way valve 11 Electronic expansion valve
6 Electric heating belt of chassis
To Next Page
