Manual No. 0-5056 6-8 Power Supply Parts List
6.05 Power Supply External Replacement Parts
Item # Qty Description Catalog #
1 Power Supply Front Panel 9-9380
1 Power Supply Rear Panel 9-9381
1 Power Supply Top Panel 9-9382
1 Power Supply Right Side Panel 9-9383
1 Power Supply Left Side Panel 9-9384
1 Louver Panel 9-9385
1 Power Supply Connections Cover 9-9386
1 Lifting Eye 9-9373
1 Touch-Up Paint (Not Shown) 9-9388
9-9380
9-9382
9-9384
9-9373
9-9386
9-9383
Art # A-04931
9-9381
9-9385
9-9385
9-9385
