INTRODUCTION 2-2 Manual 0-2844
6. Duty Cycle (see NOTE)
NOTE
The duty cycle will be reduced if the primary input
voltage (AC) is low or the DC voltage is higher
than shown in the chart.
CE CutMaster 50 Power Supply:
Ambient
Tem
p
erature
104° F
(40° C)
104° F
(40° C)
104° F
(40° C)
Duty Cycle
40% 60%
100%
Current
40 Amps 33 Amps n/a Amps
DC Voltage
110 vdc 105 vdc
n/a vdc
CE CutMaster 50 Power Supply Duty Cycle
CE CutMaster 75 Power Supply:
Ambient
Tem
p
erature
104° F
(40° C)
104° F
(40° C)
104° F
(40° C)
Duty Cycle
50% 60%
100%
Current
60 Amps 60 Amps
45 Am
p
s
DC Voltage
109 vdc 109 vdc
98 vdc
CE CutMaster 75 Power Supply Duty Cycle
CE CutMaster 100 Power Supply:
Ambient
Tem
p
erature
104° F
(40° C)
104° F
(40° C)
104° F
(40° C)
Duty Cycle
35% 60%
100%
Current
80 Amps 68 Amps
45 Am
p
s
DC Voltage
112 vdc 111 vdc
98 vdc
CE CutMaster 100 Power Supply Duty Cycle
7. Pilot Circuitry
Capacitive Discharge (CD), Ignition DC Pilot
8. Overall Dimensions (incl. handles) and Weight
CE CutMaster 50 CE CutMaster 75, 100
Length: 22.5 in. (572 mm) 27.5 in (696 mm)
Width: 10.75 in (273 mm) 12.4 in (315 mm)
Height: 16.37 in ( 416 mm) 17.3 in (439 mm)
Weight: 54 lb (24.5 kg) 85 lb (38.5 kg)
CE CutMaster Dimensions and Weights
Weight includes Power Supply w/Input Cable, Work
Lead, and Torch & Leads.
B. Gas Regulator/Filter Assembly
Specifications
The following specifications apply to the standard Gas
Regulator/Filter Assembly only:
1. Operating Pressure (Output)
70 psi (4.8 bar)
2. Maximum input gas pressure
125 psi (8.6 bar)
3. Filter
Particulate Type Filter (to 20 microns)
2.04 Power Supply Options and
Accessories
The following options and accessories are available for
this power supply. Refer to Section 6, Parts Lists, for cata-
log numbers and ordering information.
A. Single-Stage Air Filter Kit
A single-stage air filter for use on compressed air shop
systems. Highly effective at removing moisture and
particulate matter from the air stream to at least 0.85
microns.
B. Two-Stage Air Filter Kit
This two-stage air filter is for use on compressed air
shop systems. Filter removes moisture and contami-
nants to at least 5 microns. The filter assembly is pre-
assembled at the factory and need only be attached to
the power supply.
C. Extended Work Cable with Clamp
As an alternative to the factory installed 20 ft (6.1 m)
work cable & clamp on the power supply, a 50 ft
(15.2 m) work cable with clamp is available.
D. Wheel Kit (CE CutMaster 50 only)
A kit with easy-rolling wheels, for maximum portabil-
ity for the power supply.
E. Multi-Purpose Cart
Rugged steel cart on easy-rolling rear wheels and
front-mounted swivel casters. Provides maximum
mobility for the power supply and can also serve as a
display cart. Top shelf is 12 " (305 mm) x 20 (508 mm).
Steel handle is 30" (762 mm) high.
