Thermo King RD-II MAX User Manual

Electronic Controls
77
TG-V Terminal Voltage Chart
Voltages must be checked with the yellow
jacketed sensor hooked across the SN terminals
and the bulb placed in a 32 F (0 C) ice-water bath.
HSC - High Speed Cool
LSC - Low Speed Cool
LSH - Low Speed Heat
HSH - High Speed Heat
HSC
Setpoint
24 F
LSC
Setpoint
29 F
LSH
Setpoint
33 F
HSH
Setpoint
36 F
8 12 Vdc 12 Vdc 12 Vdc 12 Vdc
CH 0 Vdc 0 Vdc 0 Vdc 0 Vdc
29 0 Vdc 0 Vdc 0 Vdc 0 Vdc
10T 12 Vdc 0 Vdc 0 Vdc 12 Vdc See note below.
14T 0 Vdc 0 Vdc 12 Vdc 12 Vdc
Return Air
Sensor
SN ————
SN ————
HFL 0 Vdc 0 Vdc 0 Vdc 0 Vdc
HLO 0 Vdc 0 Vdc 0 Vdc 0 Vdc
38 0 Vdc 12 Vdc 12 Vdc 0 Vdc
7T 0 Vdc 0 Vdc 0 Vdc 0 Vdc
SP 1.95 Vdc 2.00 Vdc 2.04 Vdc 2.07 Vdc
12 12 Vdc 12 Vdc 12 Vdc 12 Vdc
11 12 Vdc 12 Vdc 12 Vdc 12 Vdc
HGV 0 Vdc 0 Vdc 0 Vdc 0 Vdc
7K 0 Vdc 0 Vdc 0 Vdc 0 Vdc
MOD (-) 0 Vdc* 0 Vdc* 0 Vdc* 0 Vdc*
(+) 0 Vdc* 0 Vdc* 0 Vdc* 0 Vdc*
Disc 8B 0 Vdc 0 Vdc 0 Vdc 0 Vdc
Sensor ————
Sensor ————
