Thermo Scientific Micro-Tech 9201 - Motherboard Jumper Settings

A-28 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
Here are the jumper settings for the Micro-Tech motherboard.
Processor Configuration Jumpers
Jumper Jumper Settings Default
J1
Jumper Setting Description
Pins 1-2 JTAG TAP Controller Enabled
Pins 2-3 Background Debug Module (BDM)
Enabled
Not Installed JTAG TAP Controller Enabled
J1 Installed 2-3
(This jumper position must not be
altered by either the user or by field
service personnel.)
J2
Jumper Setting Description
Installed Core voltage applied to pin 25 of
BDM/JTAG header
J2 Not Installed
(This jumper position must not be
altered by either the user or by field
service personnel.)
J4
Jumper Setting Description
Installed Pull-down on TCLK_PSTCLK
J4 Not Installed
(This jumper position must not be
altered by either the user or by field
service personnel.)
J5
Jumper Setting Description
Installed Enable bootloader program/erase
J5 Not Installed
(This jumper position must not be
altered by either the user or by field
service personnel.)
Motherboard
Jumper Settings
