Thermo Scientific Micro-Tech 9201 - Bit Definitions; Status Bits

C-12 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
Display Hex Hex Description
display ( 11 ) characters 1 and 2 from left of second row
display ( 20 ) characters 19 and 20 from left of second
row
display ( 21 ) characters 1 and 2 from left of third row
display ( 30 ) characters 19 and 20 from left of third row
display ( 31 ) characters 1 and 2 from left of fourth row
display ( 38 ) 4CH 20H
display ( 39 ) 20H 20H
display ( 40 ) 20H 20H characters 19 and 20 from left of fourth row
Register
Bit
Description
Status LED
15
Not Used
14
Not Used
13
Not Used
12
Not Used
11
Not Used
10
Not Used
9 Not Used
8
Not Used
7
Not Used
6
Not Used
5
Not Used
4
Zero Ready; Label: ZERO
LED #4 Green; (Applies to the currently displayed scale)
3
Zero & Span Calibration; Label: CALIB
LED #4 Red; (Applies to the currently displayed scale)
2
Alarm; Label: ALARM
LED #3 Red; (Active if any scale has an alarm)
1
Batch; Label: BATCH
LED #2 Green; (Applies to the currently displayed scale)
0
Ready; Label: READY
LED #1 Green; (Applies to the currently displayed scale)
Status(1)
15
Cumulative Shut Down
14
Cumulative Alarm
13
Calibration Running
12
Not Used
Bit Definitions
Status Bits
