Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J C-11
Register Name Description
downloaded by the user (if in Manual mode) or calculated by the integrator.
Defines when the Load Out has to stop to compensate the queue of material from
the loading point to the scale.
AZT Correction
The AZT function accurately tracks the zero of the scale, by calculating an
additional zero constant. The portion of zero due to AZT is not incorporated in the
zero constant, but is shown separately.
Auto Zero Max Dev
The current value of auto zero maximum deviation.
Total AZ %
The current value of total auto-zero %.
AZT step limit The current value of auto zero-tracking step.
Belt Warm The current value of belt warm-up time.
High Rate Set
The set point for the alarm of high rate in percent of the Scale Capacity value.
Entered or downloaded by the user.
Low Rate Set
The set point for the alarm of low rate in percent of the Scale Capacity value.
Entered or downloaded by the user.
High Speed Set
The set point for the alarm of high speed in percent of the Belt Speed Capacity
value. Entered or downloaded by the user.
Low Speed Set
The set point for the alarm of low speed in percent of the Belt Speed Capacity
value. Entered or downloaded by the user.
High Load Set
The set point for the alarm of high belt loading in percent of the Belt Load Capacity
value. Entered or downloaded by the user.
Low Load Set
The set point for the alarm of low belt loading in percent of the Belt Load Capacity
value. Entered or downloaded by the user.
Cal Error
Indicates in percent, the zero or span error computed at the end of a remote
calibration function.
The master can evaluate it before accepting the result of a remote “autozero” or
“autospan”.
Master Total Double
The current value of the master totalizer of the Micro-Tech. (In double precision
float format.)
Reset Total Double
The current value of the reset totalizer of the integrator. (In double precision float
format.)
Operator Total Double
The current value of the operator totalizer of the integrator. (In double precision
float format.)
Batch Total Double
Display Table
Display Hex Hex Description
Display ( 1 ) 2DH 20H Characters 1 and 2 from left of first row
display ( 2 ) 4DH 45H
display ( 3 ) 4EH 55H
display ( 4 ) 20H 4DH
display ( 5 ) 41H 49H
display ( 6 ) 4EH 20H
display ( 10 ) characters 19 and 20 from left of first row
