Thermo Scientific Micro-Tech 9201 - Alarm Bits

C-14 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
Register
Bit
Description
12
Not Used
11
Not Used
10
Not Used
9
Not Used
8
Not Used
7
Not Used
6 Not Used
5
Not Used
4
Not Used
3
Not Used
2
Not Used
1
Not Used
0
Not Used
Status 2 Bits 3 - 0
Description
Bit 3
Bit 2
Bit 1
Bit 0
Batch Not Running
0
0
0
0
Not Used
0
0
0
1
Batch Is Running At High Rate
0
0
1
0
Batch Is Running At Low Rate
0
0
1
1
Batch Is going To Start (Wait)/Batch Is In start Delay Time 0 1 0 0
Batch Is In Coast
0
1
0
1
Batch Hold (Suspended) at High Rate
1
0
1
0
Batch Hold (Suspended) at Low Rate
1
0
1
1
Batch Hold (Suspended) at Coast 1 1 0 1
Register
Bit
Description
Alarm
(1)
15
Clock Fail
14
Not Used
13
SIGNAL Cell Fail 1 - (Scale 1/Channel 1)
12
SIGNAL Cell Fail 2 - (Scale 2/Channel 2)
11
SIGNAL Cell Fail 3 - (Channel 3)
10 SIGNAL Cell Fail 4 - (Channel 4)
9
RAM fail
8
ROM fail
7
Speed Sensor Error
6
HIGH LOAD
5
High Load Scale # 1
4
High Load Scale # 2
3
LOW LOAD
2
Low Load Scale # 1
Alarm Bits
