Introduction
Hardware Installation
Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J 1-11
Provide a cut-out (see Figure 1–2 for dimensions) in the panel and, after
removing the holding brackets, and installing the gasket, insert the
Micro-Tech. From the back, insert the holding brackets on both sides of
the Micro-Tech. Tighten the holding brackets to support the Micro-Tech
and form a dust seal.
To connect the incoming power to the Micro-Tech, use the following
procedure. Please note that all units are 24VDC only.
1. For input power, use 16 AWG / 1.5 mmsq standard wires.
2. Wire the safety ground to the terminal labeled “E” on the Power
Input Terminal.
3. Wire the +24VDC to the terminal labeled “+” on the Power Input
Terminal.
4. Wire the 24VDC Common to the terminal labeled “–” on the Power
Input Terminal.
In most instances, your Micro-Tech is shipped to you from the factory
with all the needed jumpers installed and the switches set in the correct
positions for your particular installation and application. As a result, you
should not need to connect any jumpers or set any switches but, if you
do, all the appropriate settings are shown in Appendix A.
NOTE. Setting jumpers and switches on the Micro-Tech motherboard
must be performed only by qualified service personnel.
Incoming Power
Configuring
Jumpers and
Switches
