Thermo Scientific Micro-Tech 9201 - Premium A;D Jumper Settings

A-32 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
UART Configuration Jumpers (continued)
Jumper Jumper Settings Default
J46
COMM B Termination, (UART 2)
Jumper Setting Description
Installed 120Ω termination
J46 Not Installed
Here are the jumper settings for the Premium A/D board. (Model 9201
Micro-Tech only.)
Premium A/D Board Load-Cell Excitation Sense
Jumper Jumper Settings Default
J2
J3
J2 1-2 Installed
J3 1-2 Installed
Jumper Setting Description
Pins 1-2 Local sensing (4-wire LC)
Pins 2-3 Remote sensing (6-wire LC)
Not Installed Remote sensing (6-wire LC)
Premium A/D
Jumper
Settings
