Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J B-45
No.
Parameter
Selection
Description
2 Analog input #1
def.
Off, Inclin., moisture This scroll is only available a
2I/2O card is installed.
Angle compensation
dynamically adjusts span
when conveyor inclination
changes.
Moisture compensation is
performed on the belt loading,
and affects both rate and
totals. Only during material
calibration with material is
moisture compensation
suspended, so that the
totalized quantity can be
directly compared to the
weight obtained on a static
scale. The moisture
compensation is executed
before adding to total.
Use the CHOICE key to select
the action of the analog input,
use ENTER to confirm. Press
the CALIB softkey to calibrate.
2A
Conveyor low posit.
Moisture calib. Low
0.00 Degrees, (-35 - 35)
0.0 %M = 0.00 V (0 - 40%, 0 -
2.5 V)
With your incline sensor
installed correctly, set the
conveyor to its lowest
position. Then enter the angle
of the conveyor in this scroll.
Enter the percent moisture
and corresponding moisture
sensor voltage for the low
moisture point into this scroll.
2B
Conveyor high
posit.
Moisture calib. Hi
Degrees, (-35 - 35)
5.0 %M = 5.00 V (1-40%, 1-5
V)
With your incline sensor
installed correctly, set the
conveyor to its highest
position. Then enter the angle
of the conveyor in this scroll.
Enter the percent moisture
and corresponding moisture
sensor voltage for the high
moisture point into this scroll.
