Cablerouting:Whenyouinstallthewireless-LAN/WANantennaassembly,routethecablesasshownin
thefollowingillustration.
Attention:
Whenyouroutethecables,ensurethattheyarenotsubjecttoanytension.Tensioncouldcausethecables
tobedamagedbythecableguides,orawiretobebroken.
a b c d
Antennalocations
aWireless-LANauxiliaryantenna(black)
bWireless-WANauxiliaryantenna(blue)
cWireless-WANmainantenna(red)
dWireless-LANmainantenna(gray)
Formodelswithtouchscreen
2010LCDhingecapandLCDpanel/screenassembly
Foraccess,removetheseFRUsinorder:
112HardwareMaintenanceManual
