Rearview
1
2
3
4
3
5
6
1System-statusindicator
1
4HDMIport
2Comboaudioconnector5VGAconnector
3USB3.0connectors6Security-lockslot
1
:Forthedescriptionofthesystem-statusindicator,seeChapter5“Statusindicators”onpage45.
Bottomview
3
2
2
1
4
5
6
1Smallbottomcover
1
4Largebottomcover
2
2Batterypacklatches
5Speakers
3Batterypack6Mediacardslot
1
:Thewirelesslocal-area-network(LAN)cardandcoin-cellbatteryarelocatedunderneaththesmall
bottomcover.
2
:Thememorymodules,harddiskdriveorsolid-statedrive,andwirelessWANcardorM.2solid-state
drivearelocatedunderneaththelargebottomcover.
LocatingFRUsandCRUs
Thistopicintroducesthefollowingserviceparts:
•“MajorFRUsandCRUs”onpage52
•“LCDFRUsandCRUs”onpage54
50HardwareMaintenanceManual
