ThinkPad Edge E440 - 2040 LCD Hinges

2040LCDhinges
Foraccess,removetheseFRUsinorder:
•“1010Lenovo-OneLink-connectorcover”onpage65
•“1020Batterypack”onpage65
•“1030Largebottomcover”onpage66
•“1040Smallbottomcover”onpage67
•“1050Opticaldriveoroptical-drivebaybezel”onpage68
•“1070Harddiskdrivewithbracketorsolid-statedrivewithbracket”onpage69
•“1090Wireless-LAN/Bluetoothcard”onpage73
•“1100Coin-cellbattery”onpage74
•“1120Keyboard”onpage77
•“1130Keyboardbezelassembly”onpage83
•“1150Systemboard”onpage87
•“1170dc-in/Ethenetcardbracketanddc-in/Ethenetcard”onpage91
•“1200LCDunit”onpage96
•“2010LCDhingecapandLCDpanel/screenassembly”onpage112
RemovalstepsoftheLCDhinges
2
2
1 1
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2×3.5mm,wafer-head,nylon-coated(6)
Black0.181Nm
(1.85kgf-cm)
2
M2×3mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
Chapter9.RemovingorreplacingaFRU117
