ThinkPad Edge E440 - 2020 Camera;Microphone Module

RemovalstepsoftheLCDpanel/screenassembly
Note:Thecameraisonlyavailableonsomemodels.
1
2
2
2
1
StepScrew(quantity)Color
Torque
1
M2×5mm,wafer-head,nylon-coated(2)Silver
0.392Nm
(4kgf-cm)
2
M2×2.5mm,wafer-head,nylon-coated(3)Silver
0.392Nm
(4kgf-cm)
4
4
3
3
2020Camera/microphonemodule
Foraccess,removetheseFRUsinorder:
•“1010Lenovo-OneLink-connectorcover”onpage65
•“1020Batterypack”onpage65
•“1030Largebottomcover”onpage66
•“1040Smallbottomcover”onpage67
•“1050Opticaldriveoroptical-drivebaybezel”onpage68
•“1070Harddiskdrivewithbracketorsolid-statedrivewithbracket”onpage69
114HardwareMaintenanceManual
