ThinkPad X131e - 1110 I;O Board

StepScrew(quantity)Color
Torque
2
M2×5.5mm,shoulderscrew,nylon-coated(4)
Black0.181Nm
(1.85kgf-cm)
Wheninstalling:Attachthespeakerassemblyandroutethecableasshowninthefollowingillustration,and
ensurethatthespeakerconnectorisattachedrmly.
1110I/Oboard
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage56
•“1020Bottomslotcover”onpage57
•“1070Keyboard”onpage64
•“1080Keyboardbezelassembly”onpage67
RemovalstepsofI/Oboard
2
1
3
4
StepScrew(quantity)Color
Torque
3
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
Chapter9.RemovingorreplacingaFRU71
