ThinkPad X131e - 1140 DC-In Cable and Base Cover Assembly

13
15
16
12a
12c
12b
12d
14
Wheninstalling:Ensurethattheconnectorsareattachedrmly.
1140DC-incableandbasecoverassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage56
•“1020Bottomslotcover”onpage57
•“1040Harddiskdriveorsolid-statedriveassembly”onpage59
•“1050PCIExpressMiniCardforwirelessLAN”onpage60
•“1060PCIExpressMiniCardforwirelessWANormSATAsolid-statedrive”onpage61
•“1070Keyboard”onpage64
•“1080Keyboardbezelassembly”onpage67
•“1130Systemboardassembly,thermalfanassembly,andbackupbattery”onpage72
•“2010LCDunit”onpage77
RemovalstepsofDC-incable
1
2
Chapter9.RemovingorreplacingaFRU75
