Thinkware F100 - Front Camera (Main Unit) - Rear View; Rear Camera (Optional)

Product overview
10
1.2.2 Front camera (main unit) - rear view
REC button
• Short Press: Starts manual recording
• Press and hold for 3 seconds: Audio
recording ON/OFF
• Press and hold for 5 seconds:
Memory card format
Status LED
Indicates the operating status of the product.
Speaker
Outputs the voice guide and buzzer
sounds to indicate the product’s status.
Memory card slot
Insert a memory card to save recordings.
Microphone
Used for voice recording.
1.2.3 Rear camera (optional)
Adhesive mount
Used to fix the rear camera in the vehicle.
Rear camera lens
Records the rear view.
Security LED
Indicates that the video is being recorded.
Connection port
Used to connect the rear
camera to the front camera
using a rear camera cable.
