Thinkware Z3000Plus - Specifications

57
10. Specifications
To see the product specifications, refer to the following table.
Item Specification Remarks
Model name Z3000Plus
Dimension / Weight 106 x 66.4 x 25.7mm / 98g
Display panel FHD 2 Channel 3.2 inch TFT LCD
Memory microSD Memory card (UHS-I) 16 GB / 32 GB
Recording mode
Continuous Rec
Records videos in 1-minute segments (dual channels
are supported for recording the front and rear view)
Incident Rec
Records 10 seconds before and after the incident
(total 20 seconds)
Manual Rec
Records 10 seconds before and after manually
starting the recording (total 60 seconds)
Parking Rec (parking mode) Requires the hardwiring cable installation
Camera sensor 2.0M Pixels, 1/2.7” CMOS, 1080p
Image sensor IMX291
Angle of view 150° (based on the opposite angle)
Video
FHD (1920 X 1080) / H.264 /
file extension: MP4
Frame rate Maximum 30 fps
Audio PCM (pulse code modulation)
Acceleration sensor 3-axis acceleration sensor (3D, ±3G) 5 levels for sensitivity adjustment available
Rear camera V-IN port
Optional accessory that requires separate
purchase
Power input DC 12 / 24 V supported
Power consumption 2 CH: 3.5 W / 1 CH: 2.5 W (mean)
Except for the fully charged supercapacitor / the
LCD OFF status / GPS
Auxiliary power unit Supercapacitor
LED indicators
• Front: Security LED
• Rear: Status LED, Rec LED (2 ea)
Alarm Built-in speakers Voice guide (buzzer sounds)
Operating / Storage
temperature
-10 – 60 ℃
