Thomas PROTOUGH 900 - 1.3 Orientation; Access

T90078
1. SAFETY PRECAUTIONS
1.3 ORIENTATION / ACCESS
The following will familiarize you with the technical terms and location of
important components. Major components, control locations and indicator or
instruments can be located using the pictures provided.
Details of control operations and functions are explained in the Operations
Section 3.
7
Hydraulic fill
Top screen / plate
Bottom screen
Hopper
Hitch
Shaker deck /
head
Shaker deck / head
Engine / Hydraulic
compartment
Engine access
Control access
Oil fill
Muffler
Oil filter
Battery
Fuel filter
Oil level dip stick
Air cleaner
T90004
T90120
T90008
Fuel fill access
