THOMSON MEC 2 - V1.4 - Printed Circuit Board

MEC 2 MICROPROCESSOR ENGINE/GENERATOR CONTROLLER
PM056 Rev 6 05/10/15 Thomson Technology
15
when any pre-programmed alarm fault has been activated.
14
SHUTDOWN LED light viewing window. The SHUTDOWN LED
illuminates (flashes) when any pre-programmed shutdown fault has been
activated.
3.2. PRINTED CIRCUIT BOARD
The printed circuit board (PCB) is shown in FIGURE #11. The PCB contains the
following user interface items:
MEC 2 CIRCUIT BOARD LAYOUT









17MP1 MP2 1
TB2
TB1
IN
IC
IB
IA
VN
VC
VB
VA
WATCHDOG
REMOTE START
CRANK
RUN
COM FAIL
TB3 18 38
TB4
G:\ENGINEER\PRODUCTS\MEC2MEC2_02.VSD Rev.2 02/01/23
DRAWING SCALE (mm) = .6:1
B+ B- GRD
R115
CONTRAST
J6
Expansion
Port
FIGURE #11
