THOMSON MEC 2 - V1.4 - Programming Sheets

MEC 2 MICROPROCESSOR ENGINE/GENERATOR CONTROLLER
PM056 Rev 6 05/10/15 Thomson Technology
73
10. PROGRAMMING SHEETS
10.1. SUMMARY CONFIGURATION DATA SHEET
MEC 2
MICROPROCESSOR ENGINE/GENERATOR CONTROLLER
SUMMARY CONFIGURATION DATA SHEET
WORK ORDER #: REV: REV DATE:
INITIATED BY: CUSTOMER: DEFAULT PROGRAM:
DATE: PROJECT NAME: TPS VER:
NOTES:
ENGINE/GEN SYSTEM INPUTS
SYSTEM AC VOLTS: PHASES: FREQUENCY: DC VOLTAGE:
DIGITAL DISPLAY FEATURES
 AC VOLTAGE  AC CURRENT  BATTERY VOLTAGE
 ENGINE TEMPERATURE  KVA  TACHOMETER
 OIL PRESSURE  FREQUENCY  HOURMETER
DIGITAL FAULT CIRCUITS (15) ANALOG FAULT CIRCUITS
FAULT NAME INPUT NAME FAULT NAME INPUT NAME
Over crank Shutdown Internal Over speed Shutdown Mag-Pickup
Switch Not in Auto Alarm Internal Loss of Speed Sig. Shtdn Mag-Pickup
Emergency Stop Internal/ext Under Voltage Shutdown AC Voltage
Ext Dig Input #1 Under Frequency Alarm AC Freq
Ext Dig Input #2 Weak Battery Alarm DC Volts
Internal Under Voltage AC Voltage
Internal Over Voltage AC Voltage
Internal Under Frequency AC Frequency
Internal Over Frequency AC Frequency
Internal Over Current AC Current
Ext Dig Input #3 Low Battery Voltage Alarm DC Volts
Ext Dig Input #4 High Battery Voltage Alarm DC Volts
Low Engine Temp. Alarm Temp. Sender
High Engine Temp #1 Alm Temp. Sender
High Engine Temp #2 Shdn Temp. Sender
Low Oil Pressure #1 Alarm Press. Sender
Low Oil Pressure #2 Shutdown Press. Sender
STANDARD OUTPUT CONTACTS
OUTPUT NAME OUTPUT TYPE
Run (Fuel) Form A
Crank Form A
PROGRAMMABLE CONTACTS
OUTPUT NAME OUTPUT TYPE

ATS Test (Std Default) or Custom _____________________________________
Programmable #1 – Form C

Common Alarm (Std Default) or Custom _________________________________
Programmable #2 – Form C

Common Shutdown (Std Default) or Custom _____________________________
Programmable #3 – Form C

Engine Running (Std Default) or Custom ________________________________
Programmable #4 – Form C

EPS Supplying Load/Engine Running (Std Default) or Custom _______________
Programmable #5 – Form A/B
(EAP 110/MEC 2 Exp –Group 1 Only)

Disabled (Std Default) or Custom _____________________________________
Programmable #6 – Form A/B]
(EAP 110/MEC 2 Exp –Group 2 Only)
