THOMSON MEC 2 - V1.4 - Page 77

MEC 2 MICROPROCESSOR ENGINE/GENERATOR CONTROLLER
PM056 Rev 6 05/10/15 Thomson Technology
72
Engine
Pressure
Sender
Resistance
1
Engine
Temperature
Sensor
Resistance
KPA PSI Ohms F C Ohms
1034 150 38
392 200 20
965 140 42
374 190 24
896 130 48
356 180 28
827 120 54
338 170 33
758 110 62
320 160 39
689 100 70
302 150 46
621 90 79
284 140 55
552 80 89
266 130 65
483 70 101
248 120 76
414 60 114
230 110 90
345 50 127
212 100 106
276 40 142
194 90 147
207 30 160
176 80 197
138 20 183
150 70 290
69 10 206
140 60 426
122 50 622
104 40 952
86 30 1486
68 20 2322
50 10 3644
32 0 6284
1
Sender resistance data shown are for Oil Pressure Sender p/n-003654
(Thomson p/n), Manufacturer- Datcon, p/n 102227. Datcon Sender must
be used with MEC software version 1.81 or greater (previous software
versions cannot
be used).
Figure #18
