THOMSON RD1000 / RD1002
Edition 2 – October 2010
Receiver Descrambler - User Manual (release 7.3.1)
Transmit 1
1. Use the and buttons to move the cursor to
“Transmit 1”, then press the button. The status will
be displayed.
2. Press the button one more time to get to the Edit
screen.
3. Use the and buttons to move the cursor to
“Transmit:” then press the button.
4. Use the and buttons to set the Transmit 1 to
“Enabled” or “Disabled”, then press the button to
save the selection.
5. Use the and buttons to move the cursor to “Phys
Conn:” then press the button.
6. Choose the physical connector using the and
buttons (“Port 1” or “Port 2”) then press the button.
IP
1. Use the and buttons to move the cursor to
“IP:” then press the button.
2. Use the and buttons to select the column to
edit and use the and buttons to change the
IP, then press the button to save the selection.
Destination Port
1. Use the and buttons to move the cursor to
“Dest Port:” then press the button.
2. Use the and buttons to select the column to
edit and use the and buttons to change the
destination port (1025 – 65536), then press the
button to save the selection.
 MPEG/IP 1-4 ←→
IP:239.192.0.1
►Dest Port:01030
Source Port:01030
 MPEG/IP 1-4 ←→
►IP:239.192.000.001
Dest Port:01030
Source Port:01030
 MPEG/IP 1-4 
Receive:Enable
►Phys Conn:Port 1
IP:239.192.0.1
 MPEG/IP 1-4 
►Transmit:Enabled
Phys Conn:Port 1
IP:239.192.0.1
 MPEG/IP 1-4 
►Transmit 1
Transmit 2
