OPERATING MANUAL 2. PRODUCT DESCRIPTION
ThyssenKrupp Aufzugswerke GmbH
Traction sheave with integrated brake disk
440 mm rim diameter / 540 mm brake disk diameter
10 mm rope diameter
Number of grooves with
a) double wrap = 12 non-hardened semicircular grooves
b) single wrap = 6 - 8 seat or V-grooves for rope Ø 10 mm with hardened groove
flanks
Select the groove form (wedge angle with V-grooves or undercut angle with
seat grooves) in accordance with the necessary traction.
Weight :
Weight of machine incl. traction sheave 750 kp
Weight of machine incl. frame and rope pulley 1050 kp
Technical data dual expanding magnet:
Power supply
Retentive current: (with U
H
= 90V) 1.3 A
Pick up current: (with U
A
= 50V) 2.4 A
Rated retentive voltage: 100 V
Fast excitation: 180 V
Protection class: IP65
Series-connected coils with DAF 330.
Technical data forced ventilation:
Operating voltage: 400 – 460 V
Mains frequency: 50 / 60 Hz
Rated output: 0.27 kW
Current: 0.42 A
Air quantity: 600 m³/h
Noise level: 68 dB(A)
