ThyssenKrupp Drive DAF330 - Machine Frame

OPERATING MANUAL 2. PRODUCT DESCRIPTION
ThyssenKrupp Aufzugswerke GmbH
2.11 Machine frame DAF 330
The machine frames described below have been provided for installation in
machine room above the well.
As can be seen in the illustrations, the machine must be mounted on the
machine base frame.
Mounting bolts supplied in the bag:







































Tighten the mounting bolts
with the prescribed torque.
see chapter 8.
The supplied shims are
to be used to align the
machine
24
Version 02/2009
DAF330
