Page #31 background imageLoading...
Page #31 background image
OPERATING MANUAL 6. SERVICING
ThyssenKrupp Aufzugswerke GmbH
6. Servicing
Servicing interval: servicing of the machine should at least be carried out
once a year, preferably in the course of the general lift servicing.
Note: installation and servicing works shall only be carried out by trained and
instructed, technically competent personnel.
They shall be familiar with all directives and requirements for lift installations
as well as with the requirements for the prevention of accidents and they
shall observe them accordingly.
For further information concerning proceeding, adjustment and data see chapter:
Check brake shoes for wear, residual brake lining shall be at least
3 mm
7.2
Check brake adjustment, brake shoe stroke shall be 0.3 mm
7.2
Check brake deceleration
7.3
Check brake test switch for functioning
7.4
Check groove profile on traction sheave for damage and wear
Check screws of traction sheave fastening for correct tightening
9.1
Check grooves on rope pulley (if existing) for damage and wear
Check motor bearing for wear (noise, backlash)
Check electrical supplies for correct working and safety
Check provision and correct adjustment of protective and safety
equipment
31
Version 02/2009
DAF330
