OPERATING MANUAL 2. PRODUCT DESCRIPTION

ThyssenKrupp Aufzugswerke GmbH

Dimensions DAF 330 mounted on machine frame

Left-hand version illustrated, counterweight arranged on side

ASL = parallel d

istance of ropes at rope departure



Fig. 11

120

ASL

1220

415

330

This part is not

necessary

for frame

without rope

anchorage

Rope anchorage

2. rope anchorage if counterweight is

arranged at the rear

Fig. 12

Add. part for 2. generator

Version 02/2009

DAF330
