Traditional Signal Fixtures-9
Hall Braille
Part No. Print No. Description
9797014 169BK1 Plate, 4” x 4”, B&W, ”1”
9797117 169BK2 Plate, 4” x 4”, B&W, ”2”
9797210 169BK3 Plate, 4” x 4”, B&W, ”3”
9797312 169BK4 Plate, 4” x 4”, B&W, ”4”
9797415 169BK5 Plate, 4” x 4”, B&W, ”5”
9797518 169BK6 Plate, 4” x 4”, B&W, ”6”
9797610 169BK7 Plate, 4” x 4”, B&W, ”7”
9797713 169BK8 Plate, 4” x 4”, B&W, ”8”
9797816 169BK9 Plate, 4” x 4”, B&W, ”9”
9798316 169BK20 Plate, 4” x 4”, B&W, ”B”
9797919 169BK21 Plate, 4” x 4”, B&W, ”G”
9798018 169BK22 Plate, 4” x 4”, B&W, ”L”
9798110 169BK30 Plate, 4” x 4”, B&W, ”LL”
9796022 169BK23 Plate, 4” x 4”, B&W, ”M”
9796125 169BK24 Plate, 4” x 4”, B&W, ”P”
9798213 169BK65 Plate, 4” x 4”, B&W, ”UL”
Hall Braille
Part No. Print No. Description
9894196 169AX29 Plate, Black Plastic, ”0” (Zero) SUFFIX
9894469 169AX30 Plate, Black Plastic, ”1” SUFFIX
9894470 169AX31 Plate, Black Plastic, ”2” SUFFIX
9894482 169AX32 Plate, Black Plastic, ”3” SUFFIX
9894494 169AX33 Plate, Black Plastic, ”4” SUFFIX
9894500 169AX34 Plate, Black Plastic, ”5” SUFFIX
9894512 169AX35 Plate, Black Plastic, ”6” SUFFIX
9894524 169AX36 Plate, Black Plastic, ”7” SUFFIX
9894536 169AX37 Plate, Black Plastic, ”8” SUFFIX
9894548 169AX38 Plate, Black Plastic, ”9” SUFFIX
Hall Braille
Part No. Print No. Description
9761020 169AX20 Plate, Black Plastic, ”1” PREFIX
9761019 169AX21 Plate, Black Plastic, ”2” PREFIX
9761007 169AX22 Plate, Black Plastic, ”3” PREFIX
9760994 169AX23 Plate, Black Plastic, ”4” PREFIX
9760982 169AX24 Plate, Black Plastic, ”5” PREFIX
9760970 169AX25 Plate, Black Plastic, ”6” PREFIX
9760969 169AX26 Plate, Black Plastic, ”7” PREFIX
9894172 169AX27 Plate, Black Plastic, ”8” PREFIX
9894184 169AX28 Plate, Black Plastic, ”9” PREFIX
