Traditional Signal Fixtures-10
Hall Braille
Part No. Print No. Description
9894100 169AX1 Plate, Black Plastic, ”A”
9761070 169AX2 Plate, Black Plastic, ”B”
9894457 169AX3 Plate, Black Plastic, ”C”
9894550 169AX4 Plate, Black Plastic, ”D”
9894561 169AX5 Plate, Black Plastic, ”E”
9894573 169AX6 Plate, Black Plastic, ”F”
9761068 169AX7 Plate, Black Plastic, ”G”
9894585 169AX9 Plate, Black Plastic, ”L”
9761056 169AX9 Plate, Black Plastic, ”L”
9761044 169AX10 Plate, Black Plastic, ”M”
9894111 169AX11 Plate, Black Plastic, ”N”
9894597 169AX12 Plate, Black Plastic, ”O” ALPHA
9761032 169AX13 Plate, Black Plastic, ”P”
9894123 169AX14 Plate, Black Plastic, ”R”
9894135 169AX15 Plate, Black Plastic, ”S”
9894147 169AX16 Plate, Black Plastic, ”T”
9894159 169AX17 Plate, Black Plastic, ”U”
9894160 169AX18 Plate, Black Plastic, ”W”
9760957 169AX39 Plate, Black Plastic, STAR Symbol
Hall Braille
Part No. Print No. Description
9796502 139002 Plate, Square, 4” x 4”, #4 SS, ”1”
9796605 139003 Plate, Square, 4” x 4”, #4 SS, ”2”
9796708 139004 Plate, Square, 4” x 4”, #4 SS, ”3”
9796800 139005 Plate, Square, 4” x 4”, #4 SS, ”4”
9796903 139006 Plate, Square, 4” x 4”, #4 SS, ”5”
9797002 139007 Plate, Square, 4” x 4”, #4 SS, ”6”
9797105 139008 Plate, Square, 4” x 4”, #4 SS, ”7”
9797208 139009 Plate, Square, 4” x 4”, #4 SS, ”8”
9797300 139010 Plate, Square, 4” x 4”, #4 SS, ”9”
9797804 139013 Plate, Square, 4” x 4”, #4 SS, ”B”
9797403 139014 Plate, Square, 4” x 4”, #4 SS, ”G”
9797506 139012 Plate, Square, 4” x 4”, #4 SS, ”L”
9797609 139602 Plate, Square, 4” x 4”, #4 SS, ”LL”
9797907 139598 Plate, Square, 4” x 4”, #4 SS, ”M”
9798006 139011 Plate, Square, 4” x 4”, #4 SS, ”P”
9797701 139603 Plate, Square, 4” x 4”, #4 SS, ”UL”
