Owner’s Manual
E2010 THYSSENKRUPP ELEVATOR Printed in USA February, 2010
Signa 4 Signal Fixtures-45
Hall Key Switches
(continued)
Off Position
Indicates Key Pull
Indicates No Key Pull
Off
On
Part # DESCRIPTION Key
Bezel
(English)
Bezel
(French)
171FL1 Hall Fire Service, 2000 ANSI 204 128BP22
171FL4 Hall Fire Service, 2000 ANSI, Arizona AZFS 128BP22
171FL5 Hall Fire Service, 2000 ANSI, Rhode Island WD01 128BP22
Off Position
Indicates Key Pull
Off
Part # DESCRIPTION Key
Bezel
(English)
Bezel
(French)
171FL3 Hall Fire Service, Chicago without MTA 204 128BP74
Off Position
Indicates Key Pull
Off
Indicates No Key
Pull, Spring Re-
turn Momentary
Part #
DESCRIPTION Key
Bezel
(English)
Bezel
(French)
171FM1 Hoistway Access, Up and Down 205 128BP2 128BY14
To Next Page
