Thytronic NC20 User Manual

191
NC2 0 - Manual - 01 - 2015
APPENDIX
191
NC2 0 - Manual - 01 - 2015
APPENDIX
Description Parameter Unit Setting range
K2
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K3
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K4
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K5
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K6
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
LEDs
START
Type
No-latched | Latched
TRIP
Type
No-latched | Latched
L1
Type
No-latched | Latched
L2
Type
No-latched | Latched
L3
Type
No-latched | Latched
L4
Type
No-latched | Latched
L5
Type
No-latched | Latched
L6
Type
No-latched | Latched
Type
No-latched | Latched
Analog outputs
Current loop 1
Loop 1 Measure assigned Loop1-Mis
Frequency | IL1 | IL2 | IL3 | IL1rms | IL2rms | IL3rms
| UL1 | UL2 | UL3 | IN | INC | IL-rms | UL | IEC | PLC
| None
Loop 1 Output range Loop1-Range
0-5 mA | 0-20 mA | 4-20 mA
Loop 1 Output type Loop1-Type
Unipolar | Bipolar
Loop 1 Nominal multiplier Loop1-M
0.01 ... 100.00 step = 0.01
Loop 1 Terminals polarity Loop1-Polarity
Normal | Reverse
Current loop 2
Loop 2 Measure assigned Loop2-Mis
Frequency | IL1 | IL2 | IL3 | IL1rms | IL2rms | IL3rms
| UL1 | UL2 | UL3 | IN | INC | IL-rms | UL | IEC | PLC
| None
Loop 2 Output range Loop2-Range
0-5 mA | 0-20 mA | 4-20 mA
Loop 2 Output type Loop2-Type
Unipolar | Bipolar
Loop 2 Nominal multiplier Loop2-M
0.01 ... 100.00 step = 0.01
