Description Parameter Unit Setting range
Loop 2 Terminals polarity Loop2-Polarity
Normal | Reverse
Current loop 3
Loop 3 Measure assigned Loop3-Mis
Frequency | IL1 | IL2 | IL3 | IL1rms | IL2rms | IL3rms
| UL1 | UL2 | UL3 | IN | INC | IL-rms | UL | IEC | PLC
| None
Loop 3 Output range Loop3-Range
0-5 mA | 0-20 mA | 4-20 mA
Loop 3 Output type Loop3-Type
Unipolar | Bipolar
Loop 3 Nominal multiplier Loop3-M
0.01 ... 100.00 step = 0.01
Loop 3 Terminals polarity Loop3-Polarity
Normal | Reverse
Current loop 4
Loop 4 Measure assigned Loop4-Mis
Frequency | IL1 | IL2 | IL3 | IL1rms | IL2rms | IL3rms
| UL1 | UL2 | UL3 | IN | INC | IL-rms | UL | IEC | PLC
| None
Loop 4 Output range Loop4-Range
0-5 mA | 0-20 mA | 4-20 mA
Loop 4 Output type Loop4-Type
Unipolar | Bipolar
Loop 4 Nominal multiplier Loop4-M
0.01 ... 100.00 step = 0.01
Loop 4 Terminals polarity Loop4-Polarity
Normal | Reverse
Self-test Relay
MINOR Fail alarm
NO | YES
Self-test relay
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
MMI
Display modules
Assigned modules | All modules
46N Compensation
Compensation current IC INn 0.00 ... 0.50 step = 0.01
Compensation angle PhiC deg 0 ... 359 step = 1
Automatic compensation enable ACE
OFF | ON
Profi le selection
Active profi le
A | B | By INPUT
Profi le A
Base current IB
Base current IB In 0.10 ... 2.50 step = 0.01
Thermal protection with RTD thermometric probes - 26
PT1 Probe
ThAL1 Alarm
ThAL1 Enable ThAL1 Enable
OFF | ON
26 PT1 Alarm threshold ThAL1 ^C 0 ... 200 step = 1
ThAL1 Operating time
Value
s 0 ... 100 step = 1
ThAL1 Alarm relays ThAL1-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL1 Alarm LEDs ThAL1-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Th>1 Trip
Th>1 Enable Th>1 Enable
OFF | ON
26 PT1 Trip threshold Th>1 ^C 0 ... 200 step = 1
Th>1 Operating time
Value
s 0 ... 100 step = 1
Th>1 Breaker failure Th>1BF
OFF | ON
Th>1 Trip relays Th>1-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Th>1 Trip LEDs Th>1-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
PT2 Probe
ThAL2 Alarm
ThAL2 Enable ThAL2 Enable
OFF | ON
26 PT2 Alarm threshold ThAL2 ^C 0 ... 200 step = 1
ThAL2 Operating time
Value
s 0 ... 100 step = 1
