Thytronic NC20 User Manual

193
NC2 0 - Manual - 01 - 2015
APPENDIX
193
NC2 0 - Manual - 01 - 2015
APPENDIX
Description Parameter Unit Setting range
ThAL2 Alarm relays ThAL2-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL2 Alarm LEDs ThAL2-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Th>2 Trip
Th>2 Enable Th>2 Enable
OFF | ON
26 PT2 Trip threshold Th>2 ^C 0 ... 200 step = 1
Th>2 Operating time
Value
s 0 ... 100 step = 1
Th>2 Breaker failure Th>2BF
OFF | ON
Th>2 Trip relays Th>2-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Th>2 Trip LEDs Th>2-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
PT3 Probe
ThAL3 Alarm
ThAL3 Enable ThAL3 Enable
OFF | ON
26 PT3 Alarm threshold ThAL3 ^C 0 ... 200 step = 1
ThAL3 Operating time
Value
s 0 ... 100 step = 1
ThAL3 Alarm relays ThAL3-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL3 Alarm LEDs ThAL3-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Th>3 Trip
Th>3 Enable Th>3 Enable
OFF | ON
26 PT3 Trip threshold Th>3 ^C 0 ... 200 step = 1
Th>3 Operating time
Value
s 0 ... 100 step = 1
Th>3 Breaker failure Th>3BF
OFF | ON
Th>3 Trip relays Th>3-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Th>3 Trip LEDs Th>3-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
PT4 Probe
ThAL4 Alarm
ThAL4 Enable ThAL4 Enable
OFF | ON
26 PT4 Alarm threshold ThAL4 ^C 0 ... 200 step = 1
ThAL4 Operating time
Value
s 0 ... 100 step = 1
ThAL4 Alarm relays ThAL4-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL4 Alarm LEDs ThAL4-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Th>4 Trip
Th>4 Enable Th>4 Enable
OFF | ON
26 PT4 Trip threshold Th>4 ^C 0 ... 200 step = 1
Th>4 Operating time
Value
s 0 ... 100 step = 1
Th>4 Breaker failure Th>4BF
OFF | ON
Th>4 Trip relays Th>4-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Th>4 Trip LEDs Th>4-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
PT5 Probe
ThAL5 Alarm
ThAL5 Enable ThAL5 Enable
OFF | ON
26 PT5 Alarm threshold ThAL5 ^C 0 ... 200 step = 1
ThAL5 Operating time
Value
s 0 ... 100 step = 1
ThAL5 Alarm relays ThAL5-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
