Description Parameter Unit Setting range
I<< Element
Setpoints
I<< Logical block I<<BLK1
OFF | ON
I<< Start relays I<<ST-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I<< Trip relays I<<TR-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I<< Start LEDs I<<ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
I<< Trip LEDs I<<TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Defi nite time
37 Second threshold defi nite time
State
OFF | ON
Pickup value
In 0.05 ... 1.00 step = 0.01
I<<def Operating time
Value
s
0.04 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
Discharge time - TD
TD Enable TD Enable
OFF | ON
tD Discharge time
Value
min 0.1 ... 100.0 step = 0.1
TD Discharge time relays TD-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
TD Discherge time LEDs TD-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Phase unbalance - 46
I2> Element
Setpoints
I2> Enable I2> Enable
OFF | ON
I2CLP> Mode I2CLP> Mode
OFF | ON - Element blocking | ON - Change setting
I2CLP> Activation time
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
I2> Reset time delay
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
I2> Logical block I2>BLK1
OFF | ON
I2> Input selective block I2>BLK2IN
OFF | ON
I2> Output selective block I2>BLK2OUT
OFF | ON
I2> Breaker failure I2>BF
OFF | ON
I2> Start relays I2>ST-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I2> Trip relays I2>TR-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I2> Start LEDs I2>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
I2> Trip LEDs I2>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Defi nite time
46 First threshold defi nite time
State
OFF | ON
Pickup value
% 1 ... 150 step = 1
I2>def within CLP I2CLP>def % 1 ... 150 step = 1
I2>def Operating time
Value
s
0.05 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
I2>> Element
Setpoints
I2>> Enable I2>> Enable
OFF | ON
I2CLP>> Mode I2CLP>> Mode
OFF | ON - Element blocking | ON - Change setting
