Description Parameter Unit Setting range
I2CLP>> Activation time
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
I2>> Reset time delay
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
I2>> Logical block I2>>BLK1
OFF | ON
I2>> Input selective block I2>>BLK2IN
OFF | ON
I2>> Output selective block I2>>BLK2OUT
OFF | ON
I2>> Breaker failure I2>>BF
OFF | ON
I2> Disabling by I2>> start I2>disbyI2>>
OFF | ON
I2>> Start relays I2>>ST-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I2>> Trip relays I2>>TR-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I2>> Start LEDs I2>>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
I2>> Trip LEDs I2>>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Defi nite time
46 Second threshold defi nite time
State
OFF | ON
Pickup value
% 1 ... 150 step = 1
I2>>def within CLP I2CLP>>def % 1 ... 150 step = 1
I2>>def Operating time
Value
s
0.05 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
Neutral unbalance current - 46N
IN>AL Element
Setpoints
IN>AL Enable IN>AL Enable
OFF | ON
INCLP>AL Mode INCLP>AL Mode
OFF | ON - Element blocking | ON - Change setting
INCLP>AL Activation time
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN>AL Logical block IN>ALBLK1
OFF | ON
IN>AL Start relays IN>ALST-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IN>AL Trip relays IN>ALTR-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IN>AL Start LEDs IN>ALST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
IN>AL Trip LEDs IN>ALTR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Defi nite time
46N Alarm threshold defi nite time
State
OFF | ON
Pickup value
INn 0.01 ... 1.00 step = 0.01
IN>ALdef within CLP INCLP>ALdef INn 0.01 ... 1.00 step = 0.01
IN>ALdef Operating time
Value
s
0.04 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 500 step = 1
IN> Element
Setpoints
IN> Enable IN> Enable
OFF | ON
IN> Curve type IN>Curve
IEC/BS A | IEC/BS B | IEC/BS C | ANSI/IEEE MI |
ANSI/IEEE VI | ANSI/IEEE EI | DEFINITE
INCLP> Mode INCLP> Mode
OFF | ON - Element blocking | ON - Change setting
INCLP> Activation time
