3
Dovetail plate
Dovetail clamp
Side-to-side balance knobs
Fore-aft balance knob
Volt adjuster dials
Volt trim and pause buttons
Volt menu, mode and power LEDs
Volt gimbal connector
Accessory M12 rod threads
Dovetail clamp lever
P-tap power port
P-tap power port
Camera power port, 3pin
HD-SDI BNC ports (2)
IMPORTANT: Do not plug anything into either USB-C port (top stage or gimbal), they are for factory
programming only. The Volt electronics are not user serviceable except as shown in this guide.
Spirit level
Camera tiedown screws
Dovetail release button
Top Stage components
