Tiffen Steadicam AXIS - Table of Contents

1 Introduction to the Axis
2 Get to know the Axis components
3 Top stage
4 Gimbal
5 Base
6 Included accessories
7 Resources
8 Base assembly
10 Prepare the Axis sled
12 Attach the camera
14 Balancing the Axis
15 Static balancing
18 Dynamic balancing
20 Volt operating
21 Volt modes
22 Four dials
23 Volt pan sub-menu
24 Volt presets
26 Steadicam vest
27  Vesttting
28 Steadicam arm
29 Lifting the Steadicam
30 Arm and vest settings
32 Quick operating lessons
Maintenance and tech
34 Swap to goofy
35 Clamp adjustment
36 Gimbal index calibration
37 Connectors and pin outs
38 Accessories and part numbers
40 FAQ’s and troubleshooting
Contact Tiffen
TIP: This table of contents is hyperlinked to navigate you through the respective pages. Jump back to this
page by clicking on any page number throughout the user guide. Easy.
Table of contents
